Descrição do produto
Apresentando o Watex D65 Lens Modular Fixed LED Downlight, a compact fixed downlight designed for modern commercial and residential lighting projects. With a power range of 3-5W, this series is suitable for bathrooms, corridors, retail stores, hotel rooms, display areas, and other spaces requiring compact recessed lighting with reliable protection.
The D65 Lens version features a clean round design with lens and reflector optical options. Beam angles of 15°, 24°, 38°, and 60° allow lighting designers to create focused accent lighting, display lighting, or comfortable general illumination for different project needs.
This modular fixed LED downlight supports LED chip options such as Citizen and Bridgelux, and can be matched with driver brands including Tridonic, Osram, BOKE, TCI, and Philips. It also supports different dimming and control systems, including DALI, TRIAC, 0/1-10V, 2.4G/RF, ZigBee, and Casambi/BLE.
For lighting brands, distributors, and project contractors, the Watex D65 Lens Modular Fixed LED Downlight offers compact size, clean ceiling appearance, IP65 protection, and reliable lighting performance for professional projects.
| Watex D65 Lens Modular Fixed LED Downlight 3-5W | |||||||
| Código do produto | XH-DL-3W-WT | XH-DL-5W-WT | |||||
| Poder | 3W | 5W | |||||
| Motorista | Tridonic, Osram, BOKE, TCI, Philips | ||||||
| Tensão | AC200-240V / AC90-130V, 50/60Hz | ||||||
| Fator de potência | PF>0.90 | ||||||
| tensão do LED | DC18V | DC36V | |||||
| Corrente do LED | 150mA | 150mA | |||||
| Regulável | 0/1-10V dimmable, Phase dimmable (Triac), DALI dimmable, 2.4G/RF dimmable, ZigBee dimmable, Casambi/BLE dimmable | ||||||
| Saída de cor | Single CCT | ||||||
| Materiais | ADC12 Alumínio fundido | ||||||
| Tamanho | Ø65X49mm | ||||||
| Recortar | Ø55-60mm | ||||||
| Installation | Recessed | ||||||
| Marca LED | Citizen, Bridgelux | ||||||
| CCT | 2700K, 3000K, 3500K, 4000K, 5000K | ||||||
| CRI | Ra80+, Ra90+, Ra95+ | ||||||
| SDCM | <3 | ||||||
| Vida | 50,000h | ||||||
| Óptica | Lens | ||||||
| Ângulo do feixe | 15°, 24°, 38°, 60° | ||||||
| Eficiência da lâmpada | Lamp lumen 70-110lm/W | ||||||
| Proteção | IP65 | ||||||
| Terminar | White, Black | ||||||
| Garantia | 3-5 years | ||||||
Tamanho e desenho
Controle de intensidade luminosa
Application Scenario
Lista de produtos
| Série | Nº do produto. | Poder | Tensão do LED | Atual | Eficiência | Dimension(DXH) | Recortar | |||||||
| D65 lens | XH-DL-3W-WT | 3W | DC18V | 150mA | 70-110lm/W | Ø65X49mm | Ø55-60mm | |||||||
| XH-DL-5W-WT | 5W | DC36V | 150mA | 70-110lm/W | Ø65X49mm | Ø55-60mm | ||||||||
| D65 reflector | XH-DL-6W-WT | 6W | DC36V | 150mA | 70-110lm/W | Ø65X60mm | Ø55-60mm | |||||||
| XH-DL-8W-WT | 8W | DC36V | 200mA | 70-110lm/W | Ø65X60mm | Ø55-60mm | ||||||||
| D80 lens | XH-DL-6W-WT | 6W | DC36V | 150mA | 70-110lm/W | Ø80X50mm | Ø68-75mm | |||||||
| XH-DL-8W-WT | 8W | DC36V | 200mA | 70-110lm/W | Ø80X50mm | Ø68-75mm | ||||||||
| D80 reflector | XH-DL-10W-WT | 10W | DC36V | 250mA | 70-110lm/W | Ø80X68mm | Ø68-75mm | |||||||
| XH-DL-12W-WT | 12W | DC36V | 300mA | 70-110lm/W | Ø80X68mm | Ø68-75mm | ||||||||
